IP66 LED Street Light
Order on WhatsAppLED Street Light – Technical Specifications
| Specification | Details |
|---|---|
| Product Type | LED Street Light |
| Application | Street & Urban Outdoor Lighting |
| Light Source | LED |
| Power Consumption | 125W, 155W, 175W, 200W |
| Luminous Flux | 18000 ,23000, 26000, 30000 Lumens |
| Luminous Efficacy | 150 lm/W |
| Color Temperature | 2700K 3000K 4000K |
| Color Rendering Index (CRI) | >70 |
| LED Modules | 4 |
| Lumen Maintenance | L80 |
| Lifetime | >100,000 Hours |
| Warranty | 5 Years |
| Flicker | Flicker Free |
| Driver Type | Constant Current Driver |
| Power Factor | >0.9 |
| Dimming | 1–10V Dimmable |
| Input Voltage | 100–277V AC ±10% |
| Frequency | 50 / 60 Hz |
| Ingress Protection | IP66 |
| Impact Resistance | IK09 |
| Insulation Class | Class I |
| Operating Temperature | -30°C to +55°C |
| Body Material | Die-Cast Aluminum |
| Body Finish | Powder Coated |
| Body Color | Gray (RAL 7043) |
| Diffuser Material | Tempered Glass |
| Diffuser Thickness | 5 mm |
| Lens Material | Clear Acrylic |
| Gasket Material | Silicone |
| Mounting Options | Wall Mount, Horizontal Boom, Vertical Pole |
| Angle Adjustment | Up to ±15° |
| Electrical Compartment | Separate & Easy Access |
| Installation Aid | Bubble Level |
| Weight | 7.7 kg |
| Dimensions | 570 × 330 × 120 mm |
| Mechanical Protection | High Impact Resistance |
| Packaging | Nylon Cover & Carton |
| Optional Feature | Nano Coated Clear Glass Diffuser |
High Performance LED Street Light for Urban & Roadway Applications
This LED street light is a powerful and reliable outdoor lighting solution designed specifically for street, roadway, and urban lighting projects. With a high output of 18000 ,23000, 26000, 30000 lumens and 200W power consumption, it delivers excellent brightness while maintaining superior energy efficiency. The 2700K 3000K 4000K ensures clear visibility, making it ideal for roads, highways, parking areas, and public spaces.
Energy Efficient & Long-Lasting LED Technology
Built with advanced LED light source technology, this street light offers an impressive luminous efficacy of 150 lm/W, helping reduce electricity costs without compromising performance. The fixture supports over 100,000 hours of lumen maintenance (L80), making it a long-term and low-maintenance lighting investment for outdoor environments.
Durable Construction with IP66 Protection
The luminaire features a high-pressure die-cast aluminum body with a durable powder-coated gray finish, ensuring excellent resistance against harsh outdoor conditions. With an IP66 ingress protection rating, it is fully protected from dust, rain, and moisture. The IK09 impact resistance further enhances durability, making it suitable for demanding street and urban installations.
Advanced Optical & Electrical Design
This LED street light includes a tempered flat glass diffuser (5mm thickness) combined with a clear acrylic lens for uniform street light distribution. A constant current driver with PF > 0.9 ensures stable performance, while flicker-free lighting improves visual comfort. The fixture also supports 1-10V dimming, allowing flexible light control when required.
Flexible Installation & Smart Mechanical Features
Designed for convenience, this light supports wall mounting, horizontal boom mounting, and vertical pole mounting. Features such as ±15° adjustable angle, bubble level for accurate installation, and a separate electrical compartment make installation and maintenance easy and efficient. The operating temperature range from -30°C to +55°C ensures reliable performance in extreme weather conditions.
Ideal Applications
Urban streets & roadways
Highways & main roads
Parking areas
Commercial outdoor spaces
Public infrastructure projects
